Description
The RAM-B-176-UN4 consists of a fork stem base, double socket arm, diamand adapter base and high strength universal Finger Grip holder. This one of the cleanest ways to mount small electronics on your motorcycle. Simply slide the assembly into the hole of the stem and tighten the machine screw to create a tight fit. The universal Finger Grip holder is designed to hold a large amount of cell phones and electronic devices. The holder comes with (3 sets) of four flexible rubber coated fingers placed along sides to grip your device. The fingers open by squeezing the ends to open the small finger arms. The bottom of the holder includes a back plate that adds support to the device being held by the mount.
This part is designed to fit into the cylindrical bore wall of fork stems and will work with stems that measure from 12-20mm and 28mm or .5″-1.10″ at the following intervals:
| Metric | Standard |
|---|---|
| 12mm | .5″ |
| 14mm | .55″ |
| 16mm | .63″ |
| 18mm | .71″ |
| 20mm | .79″ |
| 28mm | 1.10″ |
This mount is designed to hold the following devices:
Cell Phones (check measurements below for dimensions) 2-Way Radios GPS Devices Works with OtterBox (Defender, Commuter, Impact) Cases, Phones with Bumper, Twisted Metal Case and More Perfect rugged solution for the Blackberry, HTC Evo, Droid X, iPhone, and More Use on your Motorcycle, ATV, UTV, Car, Boat and More Height Dimensions:
Minimum with Top and Bottom Plates: 5.25″
Maximum with Top and Bottom Plates: 6.0″
The top and bottom plates can be removed for larger devices.
Spine Plate Dimensions:
3″ Width x 3″ Height
Using Short Arm Side Clamps:
Maximum Depth: 0.75″
Minimum Width: 1.25″
Maximum Width: 3.0″
Using Medium Arm Side Clamps:
Maximum Depth: 1.25″
Minimum Width: 1.5″
Maximum Width: 3.5″
Using Long Arm Side Clamps:
Maximum Depth: 1.6″
Minimum Width: 2.25″
Maximum Width: 3.5″
Material:
High Strength Composite & Powder Coated Marine Grade Aluminum
Ball Size:
1″ Rubber Ball “B” Size
Compatible Motorcycles:
| BMW | S1000RR | 09-13 |
| BMW | R1200ST | 05-07 |
| Can-Am | Spyder RT-S SE5 | All |
| Ducati | 1199 S Panigale | 11-13 |
| Honda | CBR250R | 11-13 |
| Honda | CBR1000RR Fireblade | 08-13 |
| Honda | CBR1100XX | 96-07 |
| Honda | CBR600F | 95-98 |
| Honda | CBR600F4 | 99-00 |
| Honda | CBR600F4i | 01-06 |
| Honda | CBR600RR | 03-06 |
| Honda | CBR900RR Fireblade | 96-03 |
| Honda | CBR929 | 00-01 |
| Honda | CBR954 | 02-03 |
| Honda | ST1300 Pan European | 03-08 |
| Honda | VFR750 | 94-97 |
| Honda | VFR800 | 98-13 |
| Honda | VFR800 Interceptor | 98-01 |
| Honda | VFR800 Interceptor VTEC | 02-06 |
| Honda | VFR1200F | 09-13 |
| Honda | VTR1000F Superhawk | 97-05 |
| Kawasaki | 1400GTR | 07-13 |
| Kawasaki | 636 | 03-06 |
| Kawasaki | 650R Ninja | 06-13 |
| Kawasaki | ZX10R | 04-10 |
| Kawasaki | ZX12R Ninja | 00-05 |
| Kawasaki | ZX14R | 06-11 |
| Kawasaki | ZX6R | 98-99 |
| Kawasaki | ZX6R | 00-02 |
| Kawasaki | ZX6R | 09-12 |
| Kawasaki | ZX6R 636 Ninja | 03-06 |
| Kawasaki | ZX6RR | 00-06 |
| Kawasaki | ZX9R Ninja | 94-03 |
| Kawasaki | ZZR1200 | 02-11 |
| Kawasaki | ZZR1400 Ninja | 06-11 |
| Kawasaki | ZZR600 | 05-07 |
| Suzuki | GSXR1000 | All |
| Suzuki | GSXR1100 | All |
| Suzuki | GSXR600 | 96-10 |
| Suzuki | GSXR750 | 96-10 |
| Suzuki | Hayabusa GSX1300R | 99-13 |
| Suzuki | SV650 | 99-02 |
| Suzuki | TL1000 | All |
| Suzuki | V-Strom DL1000 | 02-13 |
| Triumph | Daytona | 06-13 |
| Triumph | Daytona 675 | 06-13 |
| Triumph | Street Triple R | 07-13 |
| Yamaha | YZF-R1 | 96-02 |
| Yamaha | YZF-R6 | 03-13 |
| Yamaha | YZF-R6S | 06-07 |
Note:
Certain motorcycles require adding electrical tape to the area of the plug that is the largest diameter until it fits snugly in the stem. RAM recommends that you review the installation instructions for this part prior to ordering.
RAM-B-176-UN4 made by Ram Mounts
