Winch Mount

Description

• Constructed of 3/16″ steel
• Metal bead blasted and powder coated for best possible finish prep and durability
• Works with the new OEM Deluxe Brushguard #2874785-067
• Complete installation instructions and mounting hardware included
• 100% made in USA
• Does NOT work with Polaris OEM Brush Guard or Double Tube Bumper.
• Roller fairlead and winch not included.
• Designed to work with the following winches:
• KFI: ST17 / A2000 / A2500-R2 / A3000 / SE25 / SE35 / AM-25 / AM-35 / AS-25 / AS-35 / U45-R2 / SE45-R2
• KFI: AS-50 (requires purchase of #4505-0952)
• WARN: VRX 25 / VRX 25-S / VRX 35 / VRX 35-S / AXON 35 / AXON 35-S / AXON 45RC require Roller Fairlead Bracket #4505-1086
• WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / RT15 / RT25 / RT30 / XT15 / XT25 / XT30
• WARN: Vantage 2000-3000 lb / Provantage 2500-3500 lb
• RAMSEY: ATV2500 / ATV3000
• SUPERWINCH: Terra25 / Terra35 / Terra 2500 (SR) / Terra 3500 (SR) / A3500 / LT2000 / LT2500 / LT3000 / UT3000 / LT4000ATV / LT4000 (SR)
• MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
• MASTER LOCK: 1500lbs #2955AT requires roller fairlead with a 4.875″ bolt pattern and drilling two 3/8″ holes in plate to fit this winch
• CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
• BADLAND 2-hole winches : 68146 / 61258 / 61297 / 61840
• BADLAND: standard winches
• CHAMPION 2-hole winches : 10028 / 10032 / 12001 / 12002 / 12003 / 12004 / 13001 / 13005 / 100127 / C20049 / C20051 / C20249 / C30045 / C30145
• CHAMPION standard winches : 10013 / 10018 / 10020 / 10024 / 12053 / 12503 / 12551 / 13004 / 13050 / 13502 / 14001 / 14051 / 14061 / 14560 / 100129 / 100218 / 100243 / 100335 / C10014 / 13060 / 13501
• KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C
• KEEPER CORP. TRAKKER: KT2000 requires roller fairlead with a 4.875″ bolt pattern
• SMITTYBILT: XRC 2.0 requires roller fairlead with a 4.875″ bolt pattern
• SMITTYBILT: XRC 3.0 / XRC 4.0
• XGEAR: X3000 / X4000 4-hole standard (3.00″ x 4.875″ bolt pattern)
• VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (standard ONLY) 4-hole standard 3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern
• Traveller: 1078088 / 1078302 require roller fairlead with a 4.875″ bolt pattern
• QUADBOSS: RP25 / RP35
• Possibly many others with standard mounting pattern of 4-hole 3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern or 2-hole 3.10” with rollers that are 4.875” bolt pattern

100430 made by KFI
